AB 5-Axis Water Jet Cutting Machine for Bevel Cutting and Taper Compensation
MAIS AB 5-Axis Water Jet Cutting Machine is designed for factories that need precise angled cutting, bevel cutting, taper compensation and complex profile cutting on stone, ceramic, glass, metal, aluminum and composite materials.
- Rated pressure: 65,000 psi, Working Pressure: 1,500–62,000 psi
- X/Y/Z + A/B five-axis CNC cutting structure
- Designed for bevel cutting and taper compensation
- Suitable for stone, ceramic, glass, metal and composites
- Cold cutting without heat-affected zone
- Custom table size, pump, voltage and machine color
- Practical 5-axis option for industrial production
AB Axis
Tilting Head Control
Cold
No Heat Damage
OEM
Custom Configuration
General Specifcations
Equipment specifications
- Model: MAI-4020
- Working size (mm): 2500*1500
- ( MPA) Rated pressure: 450(65,000 psi)
- Working pressure: 10-430(1,500–62,000 psi)
- Appearance size(mm): 5230*3130*2150
- Cutting accuracy: ±0.1mm
- Bevel cutting: 0–59°
- True 5-axis simultaneous motion
- Compatible with 3D CAD/CAM
- Heavy-duty frame for long-term industrial use
| A-axis rotation angle, power | ±59°/ 0.2KW |
| B-axis rotation angle, power | 360°/0.2KW |
| Rotation axis positioning accuracy | ±0.01mm |
| Rotation axis maximum speed | 10R/Min |
| Fixed point cutting accuracy | ±0.01mm |
| cutting accuracy | ±0.1mm (cutting tolerance of 0.2mm when the material remains undistorted). |
When Vertical Cutting Is Not Enough
Standard 3-axis waterjet cutting is suitable for flat profiles, but many workshops need angled edges, bevels, reduced taper and better fit between parts. AB 5-axis cutting helps expand your production capability without moving directly to a more complex 5-axis system.
Edge Taper Problem
Thick materials may show tapered edges after vertical cutting. AB axis movement helps compensate cutting angle for better edge results.
Need Beveled Edges
Useful for chamfers, angled edges, stone decoration, ceramic processing, metal parts and special fabrication needs.
Secondary Processing Cost
Bevel cutting directly on the waterjet can reduce manual grinding, edge trimming and additional machining steps.
Material Variety
One machine can process stone, glass, ceramic, metal, aluminum and composite materials with cold cutting technology.
What Is an AB 5-Axis Water Jet Cutting Machine?
An AB 5-axis waterjet machine adds A-axis and B-axis tilting movement to the standard X/Y/Z CNC cutting structure. The cutting head can adjust its angle during cutting, making it suitable for bevel cutting, taper compensation and controlled angled cutting.
- X-axis and Y-axis control the cutting path on the table.
- Z-axis controls cutting head height above the workpiece.
- A-axis and B-axis adjust the cutting head angle for bevel or taper compensation.
- Final cutting angle range depends on the selected cutting head and machine configuration.
Built for Practical Bevel Cutting and Stable Production
The AB 5-axis structure is suitable for buyers who need more capability than a 3-axis waterjet, while still requiring practical operation, stable structure and controlled investment.
Bevel and Angled Cutting
The AB cutting head supports controlled angled cutting for chamfers, bevels, decorative edges, stone parts, ceramic panels and metal components.
Taper Compensation
By adjusting the cutting head angle, the machine helps reduce edge taper on thicker materials and improves part fit for precision applications.
Cold Cutting for Sensitive Materials
Waterjet cutting avoids heat-affected zones, burning, hardening and thermal deformation on metal, stone, glass, ceramic and composite materials.
AB 5-Axis vs 3-Axis vs AC 5-Axis Waterjet
AB 5-axis waterjet is a practical choice between standard vertical cutting and advanced multi-angle 5-axis cutting.
| Machine Type | Best For | Key Advantage | Recommended Buyer |
|---|---|---|---|
| 3-Axis Water Jet Cutting Machine | Flat cutting, holes, curves, panels and general 2D shapes | Lower investment, easier operation and practical maintenance | Factories mainly cutting flat profiles without bevel requirements |
| AB 5-Axis Water Jet Cutting Machine | Bevel cutting, taper compensation, chamfering and controlled angled cutting | Practical 5-axis capability with stable structure and efficient production value | Stone, ceramic, metal and mixed-material workshops needing bevel capability |
| AC 5-Axis Waterjet Cutting Machine | More complex bevels, advanced angle cutting and multi-directional cutting paths | Higher cutting freedom for advanced geometry and complex processing | Factories requiring high-end 5-axis flexibility and more complex applications |
Suitable for Stone, Ceramic, Glass, Metal and Composite Materials
AB 5-axis waterjet is especially useful when the workpiece needs angled edges, cleaner fit, reduced taper or customized shape cutting.
Stone & Marble
For marble, granite, quartz, countertop openings, stone patterns, chamfered edges and decorative inlays.
Ceramic & Sintered Stone
For porcelain slabs, ceramic panels, tile decoration, brittle materials and bevel-related processing.
Glass
For decorative glass, special shapes, holes, curves and customized glass cutting applications.
Metal & Aluminum
For stainless steel, aluminum, copper, brass, carbon steel and industrial metal components.
Where AB 5-Axis Waterjet Creates More Value
This machine is designed for factories that need more than simple vertical cutting but still want a practical and reliable production solution.
Stone Bevel & Countertop Cutting
For sink holes, countertop openings, chamfers, stone patterns, marble inlays and granite decorative cutting.
Ceramic & Sintered Stone Processing
For brittle large slabs, ceramic panels, porcelain tile patterns, angle cutting and custom decorative parts.
Metal Chamfering & Part Cutting
For aluminum, stainless steel, copper, carbon steel and industrial parts requiring cold cutting and angled edges.
AB 5-Axis Water Jet Cutting Machine Specifications
Final specifications should be confirmed according to your material, cutting size, thickness, bevel angle, pump configuration and production target.
| Item | Specification |
|---|---|
| Machine Type | AB 5-Axis CNC Water Jet Cutting Machine |
| Axis Structure | X / Y / Z / A / B |
| Cutting Function | Flat cutting, bevel cutting, taper compensation, angled cutting and irregular shape cutting |
| Cutting Method | Pure water cutting / Abrasive waterjet cutting |
| Suitable Materials | Stone, marble, granite, quartz, ceramic, glass, metal, aluminum, stainless steel, copper and composite materials |
| AB Axis Angle | Optional configuration; final angle range depends on selected cutting head and project requirement |
| Cutting Table Size | Customizable according to material size and workshop layout |
| High-Pressure Pump | Customizable according to cutting thickness, speed and material type |
| Abrasive System | Automatic abrasive feeding system for hard material cutting |
| Control System | CNC control system for cutting path, speed and axis movement |
| Voltage | Customizable according to local electrical standard |
| Optional Configuration | Chiller, automatic lubrication, height sensor, spare parts package, machine color and logo customization |
| After-Sales Support | Installation guidance, operation training, spare parts support and maintenance guidance |
A Complete AB 5-Axis Waterjet Cutting System
Cutting quality depends on the full system, not only the cutting head. MAIS can configure the complete machine around your production requirement.
AB 5-Axis Cutting Head
Supports A/B axis angle movement for bevel cutting, taper compensation and controlled angled cutting.
CNC Cutting Table
Customizable table size for stone slabs, glass panels, metal sheets and large-format materials.
High-Pressure Pump
Configured according to material thickness, cutting quality requirement and production capacity.
Abrasive Feeding System
Provides continuous abrasive supply for stone, ceramic, glass, metal and other hard materials.
CNC Control System
Controls cutting path, axis movement, cutting speed, pierce points and bevel cutting programs.
Motion Structure
Stable guide rail and drive structure help maintain cutting accuracy during long working hours.
Water Tank
Collects water and abrasive, reduces splash and supports a cleaner cutting environment.
Optional Accessories
Optional chiller, height sensor, automatic lubrication, cutting software and spare parts package.
When Should You Choose AB 5-Axis Instead of 3-Axis?
Choose AB 5-axis when your cutting work requires more than vertical cutting but does not necessarily need the most complex 5-axis cutting head.
| Your Requirement | Recommended Choice | Reason |
|---|---|---|
| Only flat cutting, holes, signs, arcs and simple profiles | 3-Axis Waterjet | Lower investment and simpler operation are usually enough. |
| Need bevels, chamfers or reduced taper on flat materials | AB 5-Axis Waterjet | AB head provides practical angle control for bevel cutting and taper compensation. |
| Need advanced complex-angle cutting and more cutting head freedom | AC 5-Axis Waterjet | AC structure offers higher flexibility for more complex geometry and advanced applications. |
| Need special table size, distributor model or private label machine | OEM Waterjet Solution | Machine structure, color, logo, voltage, pump and accessories can be configured. |
Configure the Machine Around Your Material and Angle Requirement
Different workshops need different cutting sizes, bevel angles, material handling methods, pump configurations and support packages. MAIS helps you confirm the right configuration before quotation.
- Custom cutting table size and machine structure
- AB 5-axis cutting head configuration according to application
- Optional pump, abrasive system, chiller and height control
- Voltage, machine color, logo and nameplate customization
- Spare parts package and operation training support
- OEM cooperation for distributors and regional partners
From Cutting Requirement to AB 5-Axis Configuration
Send your material, cutting size, thickness, bevel angle and target application. MAIS will recommend the suitable AB 5-axis configuration.
Send Material Information
Tell us whether you cut stone, ceramic, glass, metal, aluminum, composite or mixed materials.
Confirm Cutting Requirement
Share cutting size, thickness, target bevel angle, drawings, sample photos and expected production capacity.
Confirm AB Axis Need
MAIS checks whether AB 5-axis is suitable or whether 3-axis or AC 5-axis is more appropriate.
Configure Machine System
Confirm table size, pump, cutting head, abrasive system, voltage, control system and optional accessories.
Receive Quotation
Get a quotation based on real material, application, configuration and destination country.
Production & Support
MAIS provides production coordination, delivery support, installation guidance and after-sales service.
FAQ About AB 5-Axis Water Jet Cutting Machine
What is an AB 5-axis water jet cutting machine?
It is a CNC waterjet cutting machine with X/Y/Z linear axes plus A/B tilting axes. The AB cutting head can adjust its angle for bevel cutting, taper compensation and controlled angled cutting.
What is the difference between AB 5-axis and 3-axis waterjet?
A 3-axis waterjet mainly cuts vertically on flat materials. An AB 5-axis waterjet adds cutting head angle movement, making it more suitable for bevels, chamfers and taper compensation.
What is the difference between AB 5-axis and AC 5-axis waterjet?
AB 5-axis is a practical option for controlled bevel cutting and taper compensation. AC 5-axis generally offers more cutting freedom for more complex angle cutting and advanced geometry.
What materials can the AB 5-axis waterjet cut?
It can cut stone, marble, granite, quartz, ceramic, sintered stone, glass, stainless steel, aluminum, copper, brass, carbon steel and composite materials when matched with the right configuration.
Can the AB axis angle be customized?
The available angle range depends on the selected AB cutting head and machine configuration. Please provide your required bevel angle and material thickness before quotation.
What information should I provide before requesting a quote?
Please provide material type, maximum cutting size, thickness, required bevel angle, application, production capacity, destination country and drawings or sample photos if available.
Need an AB 5-Axis Waterjet for Bevel Cutting?
Send us your material, maximum cutting size, thickness, target bevel angle, application and country. MAIS will recommend a suitable AB 5-axis waterjet configuration for your production needs.
